Schrankunterbau 630x630mm Ausführung 1, 1 Tür, 1 Schublade

Schrankunterbau 630x630mm Ausführung 1, 1 Tür, 1 Schublade

1036769102 Schrankunterbau 630x630mm Ausführung 1, 1 Tür, 1 Schublade
Item no: 1036769 102

Online price:

Availability on demand

Application
For measurement and control plates (art. no. 1036762, 1036765 and 1036766).

Execution
  • Substructure made from folded and welded sheet steel
  • Roller-mounted drawers and removable intermediate compartment
  • Doors can be locked with cylinder locks, including bearing set (three-point support and two adjusting screws for tipping protection)
  • The cabinet substructure is equipped with adjusting screws to compensate for uneven ground
  • Paint: silver grey

Delivery
Without measuring and control plate

Notes
Special paints are deliverable on request.

Brand: PLANOLITH
Plate size: 630 x 630 mm
Type: 1 Tür, 1 Schublade
Weight: 55 kg

Manufacturer part no.: 160-602
