Micrometer 50 mm MR carbide-tipped MR 250-300 mm

Micrometer 50 mm MR carbide-tipped MR 250-300 mm

Micrometer 50 mm MR carbide-tipped MR 250-300 mm
Item no: 1031505 103

Online price:

Available in 7-9 working days.

Application
For measuring shaft diameters, external dimensions etc.

Execution
  • Clamping ring for locking the spindle
  • Effect-coated
  • 50 mm measuring range
  • Anti-glare, brushed chromium-plated scale
  • Carbide-tipped measuring surfaces
  • Plane-parallel lapped
  • Spindle thread hardened and ground
  • Thermal insulation for hands
  • Zero setting and spindle nut adjustable
  • With sturdy semi-circular frame made of high-quality spheroidal graphite iron

Delivery
1x declaration of conformity
1x wooden case

Notes
For setting gauges, see art. no. 1031579.

Brand: HARTIG
Min./max. length measuring range: 250-300 mm
Vernier scale: 0.01 mm
Measuring spindle increments: 1 mm
Measuring surface diameter: 8 mm
Error limit: 0,005 mm
DIN: 863
Spindle clamping: Yes
Bracket depth: 160 mm
Number of setting dimensions: 0 PCS
Calibration Group: D

Manufacturer part no.: 4068250-300 H HHW

EAN no.: 4250099609233

Product Datasheet
