Radius cutter cyl./1835 B short, 2 cutting edges, centre cutting HSS-E 5.0 mm

Radius cutter cyl./1835 B short, 2 cutting edges, centre cutting HSS-E 5.0 mm

Radius cutter cyl./1835 B short, 2 cutting edges, centre cutting HSS-E 5.0 mm
Item no: 1016170 204

Online price:

Still in stock: 4

Application
For normal to solid steels. For cutting semi-circular grooves and pockets with rounded transitions. Suitable as a copy milling cutter.

Execution
  • Short
  • HSSE Co8
  • Uncoated
  • With face radius
  • Right-cutting
  • Right-hand twist 25°
  • Centre cutting
  • Radius tolerance +/- 0.04 mm
  • Straight shank with driving surface in accordance with DIN 1835 B

Advantage
No circular grinding chamfer, therefore better support and clear cut


Brand: LIZZARD
Material to be processed: Universal use
Cutting edge diameter: 5 mm
Radius: 2,5 mm
Cutting edge length: 8 mm
Length: 52 mm
Shank diameter: 6 mm
Number of cutting edges (Z): 2 PCS
Twist angle: 25°
Rake angle: 10 Degree
Construction length: Short
Coolant supply: External
Shank style: Cylindrical DIN 1835-B
Cutting direction: Right-hand cutting
Tolerance of shank diameter: h6
Tolerance of cutting edge diameter: h10
