ATORN thread milling cutter holder, SC A18 170 mm 12 mm HA

Versions

Item no: 1014644 103

Online price:

Catalogue price: You save:

Still in stock: 2

Min. order quantity: 1

Application
For using ground thread milling cutter inserts no. 13397.

Execution
Solid carbide steel tool holder with one insert seat

Advantage

High process reliability and dimensional accuracy due to precise insert seating
High quality solid carbide carrier material for very high requirements in terms of service life and low vibration

Brand: ATORN
Tool holding device: HA parallel shank
Coolant supply: Internal
Shank diameter (d): 12 mm
Length (l1): 170 mm

ATORN-No.: 11946056

EAN no.: 4050293264852

Product Datasheet
