Short twist drill bit DIN 338 type FS HSS-E+TiN, 3.0 mm

Short twist drill bit DIN 338 type FS HSS-E+TiN, 3.0 mm

Short twist drill bit DIN 338 type FS HSS-E+TiN, 3.0 mm
Item no: 1010053 130

Online price:

Will be ordered for you

Application
For even higher machining performance.

Execution
  • Straight shank
  • Right-cutting
  • Cone polished section
  • Thinned chisel edge
  • High concentricity
  • Precise point geometry
  • Chamfer-nitrided from 2 mm
  • Wide chip flutes and rounded rear edges for optimum chip removal

Advantage
Quality drills for the most demanding applications.

Notes
Drills for production.

Brand: ATORN
Material to be processed: Universal use
Cutting edge diameter: 3 mm
Length: 61 mm
Chip flute length: 33 mm
Max. drilling depth (D): 5xD
Angle of the tip: 130 Degree
Cutting material: HSSE
Surface: TiN
Tool holding device: Cylinder shank
Type: FS
DIN: 338
Coolant supply: External
Cutting direction: Right-hand cutting
Number of cutting edges: 2 PCS
Shank diameter: 3,0 mm
Tolerance of shank diameter: h8
f steel 700: 0,04 mm/r
