2-Punkt-Messdorn 40,1-60 mm Hartmetallmesskontakte Standardausführung

2-Punkt-Messdorn 40,1-60 mm Hartmetallmesskontakte Standardausführung

2-Punkt-Messdorn 40,1-60 mm Hartmetallmesskontakte Standardausführung
Item no: 1033844 106

Online price:

Availability on demand

Application
For quick comparison measurements of bores during series inspection.

Execution
  • Indicating plug gauge with two radially movable plungers with contact point, offset by 180°
  • Hardened steel indicating plug gauge, carbide measuring contacts
  • for dial gauges and dial indicators with a shank diameter of 8 mm

Advantage
  • ideal for series measurement
  • high level of repeat accuracy, independent of user
  • minimum measuring times
  • individually adapted to the desired bore diameter and tolerance

Delivery
OD 2-point indicating plug gauge
without display unit and device holder

Notes
When ordering, the diameter to be measured and the tolerance must be specified (for example: 35 H7 or 35 +0.15/-0.01 mm).
Other variants (hard chrome-plated measuring sleeve, measuring contacts in ruby, diamond, hard chrome-plated, 3-point or other special versions) are available on request.
For device holder, see art no. 1033844 400-402

Min./max. diameter of measuring range: 40.1-60 mm
Type: Standard
Front size: 3,5 mm
Repeat accuracy: 1 µm
Measurement travel: 0,2 mm
Connection thread: M11 x 0.75

Manufacturer part no.: 30500000

Product Datasheet
