Clamp, offset with adjustable support screw, nominal groove size 16+18 mm

Clamp, offset with adjustable support screw, nominal groove size 16+18 mm

Clamp, offset with adjustable support screw, nominal groove size 16+18 mm
Item no: 1027118 102

Online price:

Available for immediate delivery

Execution
  • Offset
  • Heat-treated steel, painted

Delivery
With adjustable support screw (without clamping screw).

Notes
Clamping range H dependent on groove depth to DIN 650, and screw-in length of the nut. The lowest clamping height is achieved by turning the clamp over. For detent clamp levers, see art. no. 1027117.

Brand: AMF
Suitable for screw: M16 | M18
Min./max. clamping height (H): 13-62 mm
Slot width (B1): 18 mm
Length (L): 125 mm
Thread diameter x thread length (D x LS): 16 x 55 mm
Clamping shoe height (A): 25 mm
Section (A1): 10 mm
Ratio (A2): 12,5 mm
Clamping shoe width (B2): 50 mm
Distance (E1): 26 mm
Slot length (E2): 45 mm
Max. clamping height: 62 mm
Min. clamping height: 13 mm
Thread diameter: 16 mm
Thread length: 55 mm

Manufacturer part no.: 6314AV M16

EAN no.: 4020772074579
