Taper sleeve DIN 69893 A HSK diameter 63 MT1 for automatic tool change

Taper sleeve DIN 69893 A HSK diameter 63 MT1 for automatic tool change

Taper sleeve DIN 69893 A HSK diameter 63 MT1 for automatic tool change
Item no: 1021846 101

Online price:

Available in 8-10 working days.

Application
For mounting Morse taper tools with flat tangs. For machine tools with automatic tool change.

Execution
Hollow shank taper with gripper groove, concentricity between the taper and internal cone less than or equal to 0.008 mm. Pre-balanced according to G 6.3 - 15,000 rpm


Brand: HHW
Mount, on tool side (MK): MK 1
Projecting length (A): 100,0 mm
Outer diameter (D): 25,0 mm
Tool holding device: HSK A63
Coolant supply: Internal
Max. concentricity: 0,008 mm

EAN no.: 4024496064700

Product Datasheet
