ATORN insert Synchrolize size 1 M3-M12 ER16.

ATORN insert Synchrolize size 1 M3-M12 ER16.

ATORN insert Synchrolize size 1 M3-M12 ER16.
Item no: 1021465 101

Online price:

Available for immediate delivery

Application
The quick-change inserts are intended for quick replacement after breakage, wear or if a different thread size is required. Tap collets are clamped using a collet mount.

Execution
  • 1x quick-change insert
  • Treated surfaces

Advantage
  • High concentricity
  • Standard collets can be used

Delivery
1x one-part quick-change insert

Notes
(Please order collets separately).

Brand: ATORN
Used sizes: 1
Collet type: ER 16
Min./max. clamping range: 2-10 mm
Suitable for thread: M3-M12
Clamp in depth off screw tap (L1): 37 mm
Projecting length (L): 24 mm
Outer diameter (D): 28 mm
Insert diameter (d): 20 mm

ATORN-No.: 21980009

EAN no.: 4050293318685

Product Datasheet
