Brand: ATORN
Shape of indexable insert ISO: T
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: G
Indexable insert type ISO: T
Size of indexable insert ISO: 11
Thickness of indexable insert ISO: 02
Corner radius of indexable insert ISO: 02
Coating: PVD
Carbide type area ISO: P
Machining conditions for indexable insert: Good
Carbide type ISO: P10
Carbide type: ATU10T
ISO-Code Rotating: TCMT 110208
Material to be processed: Cast metal | Stainless steel | Steel
min./max. ap: 0.1-1.65 mm
f min./max.: 0.05-0.2 mm/U
Materials group: P (primary application) | M (secondary application) | K (secondary application)
f min.: 0,05 mm/r
max. f: 0,2 mm/r
max. ap: 1,65 mm
min. ap: 0,1 mm
Supply type: Fine smoothing
Chip breaker code: FFP
Min./max. Vc in steel: 160-270 m/min
Min./max. Vc in cast iron: 220-350 m/min
Min./max. Vc in stainless steel: 130-240 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 12370856

EAN no.: 4050293730111

Product Datasheet
