Brand: ATORN
Shape of indexable insert ISO: T
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: T
Size of indexable insert ISO: 16
Thickness of indexable insert ISO: T3
Corner radius of indexable insert ISO: 04
Coating: CVD
Carbide type area ISO: P
Machining conditions for indexable insert: Medium
Carbide type ISO: P20
Carbide type: HC7620
ISO-Code Rotating: TCMT 16T304
Material to be processed: Cast metal | Steel
min./max. ap: 0.4-3 mm
f min./max.: 0.16-0.25 mm/U
Materials group: K (secondary application) | P (primary application)
f min.: 0,16 mm/r
max. f: 0,25 mm/r
max. ap: 3 mm
min. ap: 0,4 mm
Supply type: Medium processing - Universal geometry with wide service range
Chip breaker code: MP
Min./max. Vc in steel: 110-320 m/min
Min./max. Vc in cast iron: 140-260 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 10870619

EAN no.: 4050293352337

Product Datasheet
