ATORN insert holder DDJN, negative, left, DDJN R/L 2020 K15

ATORN insert holder DDJN, negative, left, DDJN R/L 2020 K15

ATORN insert holder DDJN, negative, left, DDJN R/L 2020 K15
Item no: 1018434 111

Online price:

Available in 6-8 working days.

Application
For copy and longitudinal turning with DN indexable insert, 55°.

Execution
Precision-manufactured steel support, burnished, hardened, adjustable clamping system, type D, working angle 93°, tip angle 55°, clearance angle 0°

Advantage
  • Streamlined geometry, optimised for contour lathe work with large feed depths and unfavourable conditions
  • Negative geometry of the body ensures good stability and force absorption at large cutting depths
  • Broad range of use: suitable for both finishing and roughing operations
  • Adjustable clamp minimises vibrations and ensures good force transfer


Brand: ATORN
ISO name: DDJN R/L 2020 K15
Shaft height (h=h1): 20 mm
Shank width (b): 20 mm
Length of head (l2): 34 mm
Length (l1): 125 mm
Programming size (f): 25 mm
Suitable for indexable inserts (ISO): DN.. 1506..
Tool design: Left
DIN: 4983

ATORN-No.: 11220060

EAN no.: 4050293127232

Product Datasheet
