ATORN ang. milling cutter, 90 deg., for APKT/APHT16, 125.0 mm, int. cooling T=9

ATORN ang. milling cutter, 90 deg., for APKT/APHT16, 125.0 mm, int. cooling T=9

ATORN ang. milling cutter, 90 deg., for APKT/APHT16, 125.0 mm, int. cooling T=9
Item no: 1017755 111

Online price:

Available in 4-6 working days.

Application
For universal use in all materials.

Execution
  • Wear-resistant, nickel-plated version
  • With internal cooling
  • Clamping screw tightening torque (indexable insert) M4 = 5.2 Nm


Brand: ATORN
Cutting edge diameter (D): 125 mm
Length (L1): 63 mm
Bore diameter (d): 40 mm
max. ap: 14,9 mm
Number of cutting edges: 9 PCS
Suitable indexable insert no. (WSP Typ): 27
Suitable indexable insert no. (WSP Typ): 28

ATORN-No.: 11117312

EAN no.: 4050293113471

Product Datasheet
