ATORN SC torus milling cutter TiAlSiN 10x12x72 mm clearance 9.6x32 mm R 1 mm

ATORN SC torus milling cutter TiAlSiN 10x12x72 mm clearance 9.6x32 mm R 1 mm

ATORN SC torus milling cutter TiAlSiN 10x12x72 mm clearance 9.6x32 mm R 1 mm
Item no: 1016785 142

Online price:

Available for immediate delivery

Application
Torus milling cutter for processing materials up to 65 HRC, e.g. for die and mould making.

Execution
  • Cutting material, Ultra Micro fine grain
  • cutting edge finish
  • HA shaft in line with DIN 6535
  • Clearance
  • type H
  • With RockTec PRO coating
  • Radius tolerance = +/- 0.005 mm

Advantage
  • optimum chip removal and temperature resistance
  • Optimised geometry for machining hard materials
  • maximum service life thanks to RockTec PRO coating


Brand: ATORN
Cutting material: SC
Surface: RockTec PRO
Type: H
Number of cutting edges (Z): 4 PCS
Twist angle: 30°
Tool holding device: HA parallel shank
Construction length: Normal
Cutting edge diameter: 10 mm
Cutting edge length: 12 mm
Clearance length: 32 mm
Length: 72 mm
Clearance diameter: 9,6 mm
Shank diameter: 10 mm
Edge radius: 1 mm
fz hard 65 HRC: 0,062 mm

ATORN-No.: 11264272

EAN no.: 4050293655018

Product Datasheet Datasheet cutting values
Versions
loading
Keywords:

You might also be interested in this

  • ATORN multi-range thr.mill.cutt. SC-TIAlN TH/BH 2 x D 9.0 mm 1.75 mm 28.8 mm HA
  •
    ATORN multi-range thr.mill.cutt. SC-TIAlN TH/BH 2 x D 16.0 mm 1.5 mm 33.8 mm HA
  •
    ATORN multi-range thr.mill.cutt. SC-TIAlN TH/BH 2 x D 9.0 mm 1.75 mm 20.1 mm HA
  •
    Hydraulic wheel jack, DIN 76024 up to 5 t overall height/max. height 212/462 mm
  •
    ATORN adjustable chamfer cutter, 10-80°, shaft diameter 25.0 mm L=100 mm T1
  •
    ATORN SK40 surface chuck (ISO 7388-1), dia. 10 mm, A=100 mm coolant bore
  •
    ATORN SK40 surface chuck (ISO 7388-1), dia. 10 mm, A=200 mm coolant bore
  •
    ATORN SK50 surface chuck (ISO 7388-1), dia. 10 mm, A=130 mm coolant bore
  •
    Low-cut safety shoe SL 645 XP blue S3 ESD size 36
  •
    BESSEY all-steel screw clamp 250 x 120 mm, bright zinc-plated with wooden handle
  •
    Form holder DIN A4 for perforated plates with hole 10x10 mm 220x310 mm
  •
