ATORN die HSS EN 22568 UNC 1/4 in tolerance 2A outer diameter 20 mm

ATORN die HSS EN 22568 UNC 1/4 in tolerance 2A outer diameter 20 mm

ATORN die HSS EN 22568 UNC 1/4 in tolerance 2A outer diameter 20 mm
Item no: 1015314 111

Online price:

Still in stock: 2

Application
For cutting UNC (Unified Coarse) threads externally in the material groups of steel and non-ferrous metals up to a strength of 700 N/mm².

Execution
right die. tol. 2A with spiral point and 1.75 pitch

Advantage
  • universal use for maximum flexibility during application
  • micro cut edge treatment and special lapping method for excellent process reliability and long service life


Brand: ATORN
Material to be processed: Steel
Thread type: UNC
Cutting material: HSS
Tolerance of dies: 2A
Thread type x nominal diameter in inches: UNC 1/4 in
Number of thread starts per inch: 20
Outer diameter: 20 mm
Height: 7 mm
Cutting direction: Right-hand cutting

ATORN-No.: 11190162

EAN no.: 4050293115741

Product Datasheet
