Die, right-cutting DIN EN 22568 with spiral point HSS MF 20 x 1.50

Die, right-cutting DIN EN 22568 with spiral point HSS MF 20 x 1.50

Die, right-cutting DIN EN 22568 with spiral point HSS MF 20 x 1.50
Item no: 1015221 234

Online price:

Still in stock: 3

Application
For metric ISO fine thread DIN 13. For materials up to approx. 800 N/mm² strength.

Execution
  • Closed (pre-slotted)
  • Spiral point for ultra-easy, clean cuts and improved surface quality
  • Chips flow forward in the cutting direction, no clogging of the chip holes
  • Tolerance field 6g
  • Chip angle 15-20°
  • Chamfer 1.75 turns


Brand: LIZZARD
Thread type: Metric fine thread
Cutting material: HSSE
Tolerance of dies: 6 g
Thread type x nominal diameter: MF20
Pitch: 1,5 mm
Outer diameter: 45 mm
Height: 14 mm
Cutting direction: Right-hand cutting
EN standard: 22568
Nominal diameter: 20 mm
Die mount diameter: 45 mm
Material to be processed: Steel

EAN no.: 4024496026999
