ATORN thr. mill. cutt., SC-TIAlN TH/BH 2xD 4.65 mm 1 mm 58 mm HA UNI

ATORN thr. mill. cutt., SC-TIAlN TH/BH 2xD 4.65 mm 1 mm 58 mm HA UNI

ATORN thr. mill. cutt., SC-TIAlN TH/BH 2xD 4.65 mm 1 mm 58 mm HA UNI
Item no: 1014610 109

Online price:

Still in stock: 2

Application
For producing metric right-hand and left-hand threads on CNC machines in through holes and blind holes in the steel, stainless steel, non-ferrous metals, cast iron and special alloy material groups up to a strength of 1500 N/mm².

Execution
Thread milling cutters with short thread section

Advantage
  • Innovative cutting geometry and high-quality cemented carbide ensure very high degree of dimensional accuracy, process reliability and chip removal
  • Tapping of very small threads from M1 x 0.2 possible


Brand: ATORN
Material to be processed: Universal use
Cutting material: SC
Surface: TiAlN
Hole type: Clearance/blind hole ≤ 2xD
Coolant supply: External
Tool holding device: HA parallel shank
Cutting edge diameter (d1): 4,65 mm
Pitch: 1 mm
Suitable for metric threads from: M6
Length (l1): 58 mm
Effective length of thread milling (l2): 14 mm
Shank diameter: 6 mm
Number of cutting edges: 3 PCS
f steel 1000: 0,07 mm/r

ATORN-No.: 11940316

EAN no.: 4050293207453

Product Datasheet Datasheet cutting values
