Machine tap Enorm 2-Z-X-PM-GLT-1 3/4-10 UNC-2BX

Machine tap Enorm 2-Z-X-PM-GLT-1 3/4-10 UNC-2BX

Machine tap Enorm 2-Z-X-PM-GLT-1 3/4-10 UNC-2BX
Item no: 1014561 111

Online price:

Available in 5-7 working days.

Application
- UNC thread
- Blind holes
- Max. drilling depth 3xD
- For universal application in almost all materials

Execution
  • Designed for use in CNC-controlled machines.
  • Increased tolerance for longer tool life in materials that are abrasive or tend to jam
  • Tapered offset guide thread
  • Longer flutes
  • DIN chamfer shape C (2-3 turns)
  • HSS-E-PM GLT-1


Brand: EMUGE
Material to be processed: Universal use
Thread type x nominal diameter in inches: UNC 3/4 in
Max. thread depth: 3xD
Thread dimension: 3/4 inch - 10UNC
Number of thread starts per inch: 10
Cutting material: HSSE-PM
Surface: TiAlN plus
Hole type: Blind hole ≤ 3xD
Tolerance of screw taps (Tol.): 2BX
Lead angle shape: C
Length: 125 mm
Cutting edge length: 30 mm
Core hole diameter: 16,50 mm
Shank diameter: 14 mm
Shank square: 11 mm
Thread type: UNC
Type: GLT-1
Twist angle: 45° (right)
Coolant supply: External
Nominal diameter in inches: 3/4 in
Shank style: Cylindrical with square drive
Cutting direction: Right-hand cutting

Manufacturer part no.: C576A601.5016

Product Datasheet Datasheet cutting values
