Through hole screw tap M DIN 371 tolerance 6G shape B 1.5xD HSS-E M4

Through hole screw tap M DIN 371 tolerance 6G shape B 1.5xD HSS-E M4

Through hole screw tap M DIN 371 tolerance 6G shape B 1.5xD HSS-E M4
Item no: 1014308 110

Online price:

Still in stock: 7

Application
- Metric thread
- Through holes
- Max. drilling depth 1.5xD
- Steels up to 800 N/mm²

Execution
  • Spiral point
  • Tolerance field 6G
  • DIN 371
  • DIN chamfer shape B (3.5-5 turns)
  • HSS-E

Notes
For workpieces that are retrofitted with a galvanic coating.

Brand: LIZZARD
Material to be processed: Steel
Thread type x nominal diameter: M4
Max. thread depth: 1.5xD
Thread dimension: M4
Pitch: 0,7 mm
Cutting material: HSSE
Surface: Uncoated
Hole type: Clearance hole ≤ 2xD
Tolerance of screw taps (Tol.): ISO 3 (6G)
Lead angle shape: B
Length: 63 mm
Cutting edge length: 13 mm
Core hole diameter: 3,30 mm
Shank diameter: 4,5 mm
Shank square: 3,4 mm
Thread type: Metric thread
Twist angle: 0°
DIN: 371
Coolant supply: External
Nominal diameter: 4 mm
Shank style: Cylindrical with square drive
Cutting direction: Right-hand cutting
