EINLIPPEN-TIEFLOCHBOHRER E80 20XD MIT TICN VHM-KOPF GERADE HA Ø 13,0

EINLIPPEN-TIEFLOCHBOHRER E80 20XD MIT TICN VHM-KOPF GERADE HA Ø 13,0

EINLIPPEN-TIEFLOCHBOHRER E80 20XD MIT TICN VHM-KOPF GERADE HA Ø 13,0
Item no: 1011300 130

Online price:

Available in 6-8 working days.

Application
for use in alloyed and high-alloy steels

Execution
  • Circumferential shape G
  • without chip divider groove
  • 20xD


Brand: HARTNER
Material to be processed: Universal use
Cutting edge diameter: 13 mm
Tolerance of cutting edge diameter: h5
Cutting material: SC
Surface: TiCN
Max. drilling depth (D): 20xD
Type: TLB E80
Coolant supply: Internal
Tool holding device: HA parallel shank
Shank diameter: 20 mm
Length: 390 mm
f steel 1000: 0,035 mm/r
Cutting direction: Right-hand cutting
Number of cutting edges: 1 PCS
Tolerance of shank diameter: h6

Manufacturer part no.: 9895140130000

EAN no.: 4031096350393
