ATORN solid carbide drill UNI TiAlNplus 8xD with IC 3.1 mm

ATORN solid carbide drill UNI TiAlNplus 8xD with IC 3.1 mm

ATORN solid carbide drill UNI TiAlNplus 8xD with IC 3.1 mm
Item no: 1011167 111

Online price:

Still in stock: 2

Application
for HPC boring up to a strength of 1300 N/mm²

Execution
  • solid carbide TiAlNplus high-performance drill
  • 4 drill heels
  • Four grinding faces
  • 30° spiral angle
  • Straight main cutting edge

Advantage
  • economic drilling in a wide variety of materials with high cutting values
  • newly developed geometry in conjunction with a multi-layer coating individually tailored to drilling ensures significantly longer service lives
  • Cutting edge finishing reduces micro-fractures and increases the service life
  • very high alignment accuracy thanks to 4 drill heels
  • high process reliability even at extreme depths


Brand: ATORN
Material to be processed: Universal use
Cutting edge diameter: 3,1 mm
Tolerance of cutting edge diameter: h7
Cutting material: SC
Surface: TiAlN plus
Max. drilling depth (D): 8xD
Type: HPC UNI
Coolant supply: Internal
Tool holding device: HA parallel shank
Angle of the tip: 135 Degree
Shank diameter: 6 mm
Chip flute length: 34 mm
Length: 72 mm
f steel 1000: 0,11 mm/r
DIN: 0 - not applicable

ATORN-No.: 10915478

EAN no.: 4050293530407

Product Datasheet Datasheet cutting values
