NC spotting drill, solid carbide 120°, diameter 10 mm x 89 mm HB shaft

NC spotting drill, solid carbide 120°, diameter 10 mm x 89 mm HB shaft

NC spotting drill, solid carbide 120°, diameter 10 mm x 89 mm HB shaft
Item no: 1010906 310

Online price:

Still in stock: 4

Application
For 120° spot drilling for the following twist drills on CNC machines.

Execution
Spiral-fluted design

Advantage
  • Short design with precise point geometry and chisel edge ensure form-true and process-reliable spot drilling
  • The follow-on tool does not run off centre
  • Precise gauge thanks to special point thinning of the chisel edge

Notes
Diameter less than 6 mm with HA shaft

Brand: ATORN
Material to be processed: Steel | Stainless steel | Non-ferrous metal | Cast metal | Special alloy
Angle of the tip: 120 Degree
Cutting material: SC
Surface: Uncoated
Tool holding device: HB parallel shank
Cutting edge diameter: 10 mm
Cutting edge length: 25 mm
Length: 89 mm
f steel 1300: 0,16 mm/r

ATORN-No.: 10916128

EAN no.: 4050293695434

Product Datasheet Datasheet cutting values
